MVR3EBC is a range measurement sensor of MoeVision Ranger3 series, using TOFTime-ofFight time of flight technology,940nm VCSEL light source, combined with unique optical, electronic, structural design of laser ranging cross group, can achieve 03 to 14 meters /28 meters high speed ranging requirements (indoor and outdoor). Provides HEX and ASCI UART serial port output data formats. Through rigorous temperature, ambient light and linear compensation, accurate distance information can be obtained in different environments.
Advantages and characteristics
?Measuring distance: 0.3~14m/0.3~28m
?Measurement speed: adjustable from 1 to 200Hz
?Small size: 44.5*18.46*19.2mm
?Weight: 7g
