MVR2TB 10m Economical Small Volume Ranging Module
  • 1.Measuring range: 0.1~14m (90% reflectivity)
  • 2.Resolution: 10mm
  • 3.Accuracy: ±6cm (0.2~7m); ±2% (7~14m)
  • 4.Measurement speed: 10/20/50/100Hz adjustable (automatic measurement)
  • 5.Interface: UART TTL
  • 6.Operating temperature: -10~+60℃

網(wǎng)站主圖

MVR2TB is MOEVISION Ranger 2 series of cost-effective ranging module, using TOF(time-of-flight Time of Flight) technology, 940nm light source, with a unique optical, electronic, structural design of laser ranging module, can achieve 0.1 to 14 meters of high-speed ranging requirements.


MVR2TB provides HEX and ASCII UART serial output data formats. The range module can obtain accurate distance information in different environments through rigorous temperature, ambient light and linear compensation. The two M2 metal nut bits at the bottom can make the installation more stable and secure, and can be loaded and unloaded repeatedly.


Advantage feature

· Measuring distance 0.1-14 meters

· The measurement speed is adjustable from 1 to 100Hz

· Centimeter-level accuracy is poor

· Adjustable distance threshold Control IO High/Low level (TTL)

· Small and exquisite: 30*16*24mm, weight 9 grams




MVR2TB技術(shù)參數(shù)

1697450521811
